Specifications
- 4G / GSM emergency intercom for elevators
- Meets valid EU standards for installation in elevators
EN 81-28
EN 81-70
- 4G (VoLTE – Voice over LTE) / 2G GSM version
- 2-wire line connection between the emergency intercom in the elevator car and the 4G GSM gateway in the machine room
- The elevator intercom is powered only by the analog line
- Simple programming with one SMS text message
- The 4G GSM gateway is not programmed in any way during the installation, it remains in the factory settings
- The 4G GSM gateway has an SMS programming function for the Lift-Call-Line intercom
- The Lift-Call-Line elevator intercom is programmed via a 4G GSM gateway using an SMS message
- Possibility of communication with the engine room
- The possibility of connecting two more intercoms above the elevator cabin and below the elevator cabin
- Status indication using internal LEDs or an optional set of external LEDs (green/yellow) can be connected
- Fault status indication according to EN standards
- Technical and service calls
- Checking the functionality of the acoustic path
- Checking for a stuck button
